Kingfa Abs Kf-740: High Flow Hb Flame Retardant Grade For Thin-wall Molding

prime union plasticPLASTIC MATERIAL SOLUTION EXPERT

ABS KF-740

KINGFA ABS KF-740 is a high fluidity (35g/10min) HB flame retardant ABS with excellent dimensional stability and impact strength (20 kJ/m²). Ideal for large thin-wall office equipment and home appliances. Supplied by Qingdao Prime Union Trade, an authorized distributor. Get TDS and samples.

KINGFA ABS KF-740 is a high-flow injection molding grade ABS resin from KINGFA, featuring UL94 HB flame retardant rating (1.6mm). It is specially designed for large thin-wall components, office equipment, and home appliance housings. This grade offers a balanced combination of high melt flow, dimensional stability, and moderate impact resistance, enabling efficient processing and reliable part performance.

ABS KF740

Technical Data Sheet

Property	Test Standard	Value	Unit
Physical
Density	ISO 1183	1.05	g/cm³
Molding Shrinkage	ISO 2577	0.4~0.7	%
Flow
Melt Flow Index (220°C, 10kg)	ISO 1133	35	g/10min
Mechanical
Tensile Strength (50mm/min)	ISO 527	45	MPa
Elongation at Break	ISO 527	25	%
Flexural Strength	ISO 178	72	MPa
Flexural Modulus	ISO 178	2500	MPa
Izod Impact Notched (23°C)	ISO 180	20	kJ/m²
Thermal
Heat Deflection Temp (0.45MPa)	ISO 75	85	°C
Heat Deflection Temp (1.8MPa)	ISO 75	77	°C
Vicat Softening Temp (50°C/h, 50N)	ISO 306	97	°C
Flammability
Flame Rating (1.6mm)	UL94	HB
Electrical
Volume Resistivity	IEC 60093	1E+14	Ω.cm
Dielectric Strength	IEC 60243	22	KV/mm

Key Features & Applications

High Fluidity: With MFI of 35g/10min (220°C/10kg), KF-740 easily fills long flow paths and complex geometries, making it ideal for thin-wall injection molding.
Dimensional Stability: Low and uniform shrinkage ensures tight tolerances for assembled parts.
Balanced Toughness: Notched impact strength of 20 kJ/m² provides good resistance against everyday impacts.
Easy Coloring: Can be colored to meet various aesthetic requirements.

Typical Applications:

Office equipment enclosures (printers, copiers)
Large home appliance parts (TV backs, vacuum cleaners)
Thin-wall containers & toys
Electronic housing requiring HB rating

Why Choose Qingdao Prime Union Trade?

Qingdao Prime Union Trade Co., Ltd has over 24 years of experience in distributing engineering plastics. We are authorized distributors for CHIMEI, Hyosung, Hanwha, and have a direct partnership with KINGFA. This ensures every batch of KF-740 ABS is prime virgin material with full traceability.

Through our sister company, Qingdao Primetech Plastics (19 years in compounding), we offer more than just standard grades. Need custom colors, enhanced UV resistance, or specific impact modifiers? We can provide tailor-made compounds based on KF-740 to meet your exact requirements, along with technical support for injection molding.
